Features

• Twenty-four 10/100 switched RJ-45 ports deliver up to 200 Mbps of throughput per port
• Two 10/100/1000 switched RJ-45 Gigabit uplink ports (with two shared mini Gigabit Interface Converter [mini-GBIC] ports)
• Switching capacity delivers 8.8 Gbps, nonblocking capacity
• WebView monitoring allows administrators to view the current status and configuration using their favorite web browser
• Port-based and 802.1Q-based VLANs support up to 128 VLANs
• Port trunking for up to four groups (with up to eight ports in a group) allows you to increase your bandwidth for each uplink or server connection
• Port configuration settings for link, speed, automatic medium dependent interface (MDI) and MDI crossover (MDI-X), flow control, and more
• Fully rack mountable using the included rack-mounting hardware
• Auto MDI/MDI-X per port allows for automatic cable detection
• MAC address table supports up to 8000 entries
• Optimal platform to support real-time applications such as voice and video, with features like IGMP snooping, multiple queues (four) with appropriate scheduling techniques, prioritization of traffic based on Layer 2/Layer 3 priority, and line rate forwarding mechanisms
• Secure control with SSL for HTTP interface
• User/network security via 802.1X (with RADIUS authentication) and MAC-based filtering
• Containment of storms - broadcast and multicast
• Expandability and availability increased across multiple switches using link aggregation
• SNMP and RMON management expand your visibility options
